Description:
TRAIRF® HEPA Air Filter is made of ultra-fine fiberglass, it
designed into continuity fold paper for providing larger filtration
area. Mini-pleats media design also can extending filter life and
decreasing filter pressure drop. Air can through media smoothly
with low resistant. What’s more, folded media separated through hot
melt adhesive to make sure there are no chemical pollution air
release to our clean space. TRAIRF®HEPA Filter testing according to
EN-1822 standard, filtration efficiency guaranteed from 99.97 % to
99.999 % for particles size at 0.3 micro meter.
Part Name | High Efficiency Fiber Glass Hepa Air Filter h14 |
Shape | Panel Filter |
Porosity | 0.3um |
Size | Standard Size (Customized) |
Colour | Silver |
Structures | Aluminum Alloy Frame and Fiberglass Pleated Pack (Customized) |
Filtering Efficiency Grade | 99.99% |
Special Properties | High Efficient, High Dust Holding Capacity, Long Service Life |
Efficiency:
The series provide guarantee efficiency from 95.99%, 97.99%,
99.999% (EU12-EU14) or H10-H14 (per EN-1822 standard in MPPS Test)
on 0.3 micrometer size particles HEPA filter.
| Testing Method |
| Particle Size(um) | 0.3um | 0.1-0.2um |
| Efficiency(%) | 95% | 99.999% above |
| 99.97% |
| 99.99% |
| 100.00% |
| According to EN-1822 standard in MPPS Test |
Material:
Metal Frame (Galvanized Steel and Aluminum in box type or header
type) are available. TRAIRF® high efficiency particulate Air Filter
provide the maximum effective media area. With the advantages of
long life span, light weight, easy handling of rejection and
environment friendly.
